Compatible with Corning-OptiTap and H-Connector;
Cable length 50m, 100m, 150m, 200m, 250m or customized;
Factory terminated for high performance;
Available with one or both ends connectorized;
Hybrid (one end with an OptiTap Connector, one end with standard SC connector) available with or without pulling grip;
Available in dielectric or toneable;
Designed for aerial, direct-buried or duct installation;
IP68 water and dust protection ;
-40℃~85℃ operating temperature;
Compatible with Corning-OptiTap and H-Connector;
Cable length 50m, 100m, 150m, 200m, 250m or customized;
Factory terminated for high performance;
Available with one or both ends connectorized;
Hybrid (one end with an OptiTap Connector, one end with standard SC connector) available with or without pulling grip;
Available in dielectric or toneable;
Designed for aerial, direct-buried or duct installation;
IP68 water and dust protection ;
-40℃~85℃ operating temperature;
FTTH;
For connection between distribution box and RRH;
Outdoor Areas;
Harsh Environment.
FTTH;
For connection between distribution box and RRH;
Outdoor Areas;
Harsh Environment.
Item | Parameter |
Connector type | SC/APC OptiTap connector(H Connector) |
Cable diameter | 5.0mm round cable or 4.5*8.1mm flat cable |
Connector insertion loss (dB) | ≤0.3 |
Connector return loss (dB) | ≥ 50dB (UPC) ,≥ 60dB (APC) |
Cable pull | 120N, IEC 61300 |
Waterproof | IP68 |
Working temperature | -40℃~85℃ |
Storage Temperature | -40℃~85℃ |
Item | Parameter |
Connector type | SC/APC OptiTap connector(H Connector) |
Cable diameter | 5.0mm round cable or 4.5*8.1mm flat cable |
Connector insertion loss (dB) | ≤0.3 |
Connector return loss (dB) | ≥ 50dB (UPC) ,≥ 60dB (APC) |
Cable pull | 120N, IEC 61300 |
Waterproof | IP68 |
Working temperature | -40℃~85℃ |
Storage Temperature | -40℃~85℃ |
